Collant Pump for Air Treatment System

Collant Pump For Air Treatment System

Specification:

  • Extend Force Tolerance 0~10% Of Named Force
  • Stroke T Tolerance of 0 ~ 0.5mm
  • Stud Mounting Dimension C – C Tolerance of 0 ~ 0.5mm
  • Ball Joint (Stud And Socket), Fitting Gap (Axial And Radial) from 0.1mm ~ 0.3mm
  • Life Span of >30,000 Cycles, No Leakage
  • Apparent Damping Function For Last 1/3 Travel
  • Gas Spring Consistency And Motion Quality



Usages:

The pumps are suitable to transfer liquids containing impurities measuring up to 2-3 mm.The hydraulic components, namely the impeller, scroll and pump body in PBT allow the pumps to be used with water, emulsions and oily substances in general with a maximum viscosity of 3° Engler (21 CST).

The temperature of the liquid must not exceed 70°.

They are usually used on:

– Air-conditioning systems
(for Licl solution transferring)
– Machine tools
– Filtration systems

They should usually be installed on a tank, with a capacity in proportion to the flow rate, at about 3-4 cm. from the bottom. It is important to check that the maximum level of the liquid in the tank always remains 3-4 cm. lower than the flange In cases where the liquid is particularly dirty, the user is recommended to construct the tank in compartments to allow the dirt to deposit before it is stirred up by the pump.

DOWNLOAD BROCHURE
Gas Spring models are listed according to Total Length by Force (N). For where to measure Total Length, please refer to the diagram above for (C-C) Stock List Of Industrial Gas Springs: Models are listed according to Total Length by Force (N) For more information on Total Length, please refer to the diagram above for (C-C)
  • 157 mm
    • 100 N
    • 150 N
  • 165 mm
    • 60 N
    • 80 N
    • 100 N
    • 120 N
    • 150 N
    • 170 N
  • 205 mm
    • 120 N
    • 200 N
  • 238 mm
    • 30 N
    • 50 N
    • 70 N
    • 100 N
    • 150 N
    • 200 N
    • 250 N
    • 300 N
  • 245 mm
    • 60 N
    • 100 N
    • 120 N
    • 160 N
  • 250 mm
    • 80 N
  • 255 mm
    • 300 N
  • 275 mm
    • 300 N
    • 350 N
  • 300 mm
    • 300 N
    • 350 N
  • 306 mm
    • 200 N
  • 310 mm
    • 120 N
    • 130 N
    • 140 N
    • 350 N
  • 315 mm
    • 40 N
    • 100 N
    • 150 N
    • 180 N
    • 200 N
    • 230 N
    • 250 N
    • 300 N
    • 400 N
    • 450 N
    • 500 N
    • 530 N
  • 324 mm
    • 890 N
  • 340 mm
    • 300 N
  • 358 mm
    • 90 N
  • 385 mm
    • 100 N
    • 200 N
    • 250 N
    • 300 N

Stacker / Positioner E100

Features:

  • Easy To Operate
  • Rechargable Battery
  • Able to handle up to 100 Kg
  • Mobile Plateform for ease of moving

Specifications:

  • Load Capacity : 100 Kg
  • Load Center : 235 mm
  • Max. Fork Height : 1700 mm
  • Min. Fork Height : 130 mm
  • Platform Size : 470 mm x 600 mm
  • Overall Size : 870 mm x 600 mm x 1990 mm
  • Battery : 24 V / 12 Ah
  • Net Weight : 66 Kg
